Imprimante transfert thermique Code barre étiquettes EZ120/G500

Imprimante Transfert thermique Pour etiquettes GODEX EZ120 EQUI G500 Bureautique Tres Robuste Made in taiwan
Taille d'impression max 108mm.
Ruban 350m.

Fiche technique

Model EZ120
Print Method Thermal Transfer / Direct Thermal
Resolution 203 dpi (8 dots/mm)
Print Speed Up to 4 IPS (102 mm/s)**
Print Width 4.25” (108 mm)
Print Length Min. 0.16” (4 mm)** Max. 68” (1727 mm)
Processor 32 Bit RISC CPU
Memory 8MB Flash (4MB for user storage) ; 16MB SDRAM
Sensor Type Adjustable reflective sensor
2 fixed transmissive sensors, central aligned
Media Types : Continuous form, gap labels, black mark sensing, and punched hole; label length set by auto sensing or programming
Width : 1” (25.4 mm) Min. - 4.64” (118 mm) Max.
Thickness : 0.003” (0.076 mm) Min. - 0.01” (0.25 mm) Max.**
Label Roll Diameter : Max. 5” (127 mm)
Core Diameter : 1” (25.4 mm), 1.5” (38.1mm), 3” (76.2mm)
Ribbon Types : Wax, wax / resin, resin
Length : 981’ (300 m)
Width : 1.18” Min. - 4.33” (30 mm - 110 mm) Max.
Ribbon Roll Diameter : 2.67“ (68 mm)
Core Diameter : 1” (25.4 mm)
Printer Language EZPL, GEPL, GZPL, GDPL auto switch
Software Label design software: GoLabel (for EZPL only)
Driver: Vista, Windows 7, Windows 8 & 8.1, Windows 10, Windows Server 2008 R2, 2012, 2012 R2, 2016, 2019, MAC, Linux
SDK: Win CE, .NET, Windows Vista, Windows 7, Windows 8 & 8.1, Windows 10, Android, Mac, iOS
Resident Fonts Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B
Bitmap fonts 0°, 90°, 180°, 270° rotatable, single characters 0°, 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
TTF Fonts: TTF Fonts (Bold / Italic / Underline ). 0°,90°, 180°, 270° rotatable
Download Fonts Bitmap fonts: 0°, 90°, 180°, 270° rotatable, single characters 0°, 90°, 180°, 270° rotatable
Asian fonts: 16x16, 24x24. Traditional Chinese (BIG-5), Simplified Chinese(GB2312), Japanese(S-JIS), Korean (KS-X1001)
0°, 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical directions
TTF fonts: TTF Fonts (Bold / Italic / Underline ). 0°,90°, 180°, 270° rotatable
Barcodes 1-D Bar codes:
China Postal Code, Codabar, Code 11, Code 32,Code 39, Code 93, Code 128 (subset A, B, C), EAN-8/EAN-13 (with 2 & 5digits
extension), EAN 128, FIM, German Post Code, GS1 DataBar, HIBC, Industrial 2 of 5 , Interleaved 2-of-5 (I 2 of 5), Interleaved 2-of-5 with
Shipping Bearer Bars, ISBT-128, ITF 14, Japanese Postnet, Logmars, MSI, Postnet, Plessey, Planet 11 & 13 digit, RPS 128, Standard 2 of 5,
Telepen, Matrix 2 of5, UPC-A/UPC-E (with 2 or 5 digit extension), UCC/EAN-128 K-Mart and Random Weight
2-D Bar codes:
Aztec code, Code 49,Codablock F , Datamatrix code, MaxiCode, Micro PDF417, Micro QR code, PDF417,QR code, TLC 39, GS1
Composite
Code Pages Codepage 437, 737,850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869
Windows 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8、UTF16BE、UTF16LE
Graphics Resident graphic file types are BMP and PCX, other graphic formats are downloadable from the software
Interfaces USB Device (B-Type)
Control Panel One Tri-color LED : Power (Green, Orange and Red)
Function Key : FEED
Real Time Clock N/A
Power Auto Switching 100-240VAC, 50-60Hz.
Environment Operation temperature: 41°F to 104°F (5°C to 40°C)
Storage temperature: -4°F to 122°F (-20°C to 50°C
Humidity Operation: 30-85%, non-condensing.
Storage: 10-90%, non-condensing.
Agency Approvals CE (EMC), FCC Class A, CB, CCC, UL, cUL, UKCA
Dimension Length : 11.2” (285 mm)
Height : 6.8” (171 mm)
Width : 8.9” (226 mm)
Weight 6 lbs (2.72 Kg) ,excluding consumables
Options External label roll holder for 10” (250 mm) O.D. label rolls
External label rewinder T10
Note *Specifications are subject to change without notice. All company and/or product names are trademarks and/or registered trademarks of theirrespective owners.
**Minimum print height and maximum print speed specification compliance can be dependent on non-standard material variables such as label type, thickness, spacing, liner construction, etc.
GoDEX is pleased to test non-standard materials for minimum print height, and maximum print speed capability.

List of Avaialble GoDex Printers: DT2x, DT4x, EZ2250i, EZ6250i, EZ120, G500, GE300, MX20, MX30, MX30i, RT200, RT200i, RT700, RT700i, RT863i, ZX400i, 2X420, ZX1000, ZX1000i
طابعة باركود احترافية جوديكس GoDEX EZ120

دقة الطباعة 203 DPI

نمط الطباعة: حراري مباشر (بدون شريط حبر) او بالنقل الحراري (مع شريط حبر)

سرعة الطباعة: حتى 102 ملم / ثانية

عرض منطقة الطباعة: حتى 108 ملم

ارتفاع منطقة الطباعة: حتى 1727 ملم

عرض الورق: من 25.4 ملم حتى 118 ملم

التباعد بين الاستيكرات: 2 ملم او اكثر

اللون المتاح: اسود

مزودة بمنافذ: USB

صنع في تايوان
