LiuGonG SG50A 2023

Specifications
SG50ACompare product
Wall width 0.3-1.5 m
Wall depth 75 m
Max extraction force 500 kN
Single line pull 2×250 kN
Hydraulic system pressure 33 MPa
Hydraulic system flow 2×380 L/min
Frame weight 14-25 t
Machine weight(without shovel) 72 t
Working height 18380 mm
Max lifting height 4500-5500 mm
Overall crawler length 5820 mm
Distance between center frame and swing center 4675-5345 mm
Swing radius of rearend 4390 mm
Engine QSM11-Tier3
Max speed 1900 rpm
Rated output 266 kW
Undercarriage Model JT80
Outer distance of crawler 3300-4400 mm
Track shoe width 800 mm
Traction force 580 kN
Travel speed 1.5 km/h

علبة السرعة: Automatique

الوقود: Diesel

سنة الصنع: 2023

الفئات: مركبات أخرى

المنطقة: تيزي وزو / الجزائر

وضع في: 15-12-2023 à 10:46:13

عدد المشاهدات: 0
