Differences are marked in red
SPATIUM M480 PRO PCIe 4.0 NVMe M.2 1TB
SPATIUM M480 PRO PCIe 4.0 NVMe M.2 2TB
SPATIUM M480 PRO PCIe 4.0 NVMe M.2 4TB
Model Name SPATIUM M480 PRO PCIe 4.0 NVMe M.2
Capacity 1TB 2TB 4TB
Controller PHISON E18
Flash Memory 3D NAND
DRAM Cache 1GB DDR4 2GB DDR4 2GB DDR4
Form Factor M.2 2280
Interface PCIe Gen4 x4, NVMe 1.4
Compatibility PCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions 80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s) 7400
Sequential Write up to (MB/s) 6000 7000 7000
Random Read 4KB up to (IOPS) 750,000 1,000,000 1,000,000
Random Write 4KB up to (IOPS) 1,000,000
Maximum Operating Power (W) 9.5 10.5 11.3
Idle Power PS3 (mW) 40 45 50
Low Power L1.2 (mW) 3
Operating Temperatures 0°C – 70°C
Storage Temperatures -40°C – 85°C
Terabytes Written (TBW) 700 1400 3000
Mean Time Between Failure (MTBF) Up to 1,600,000 Hours
Limited Warranty 5 Years, or the coverage for the maximum TBW as stated, whichever comes first.
Advanced Features TRIM (Performance Optimization, OS Support required)
SMART (Self-Monitoring, Analysis and Reporting Technology)
LDPC (Low Density Parity Check) ECC Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/Pyrite (Encryption, Data Security)
