ModelMPE-C501-AFCAG-3
ATX VersionATX Rev. 3.0
PFCActive PFC
Input Voltage100-240V
Input Current15-7A
Input Frequency50-60Hz
Dimensions (L x W x H)180 x 150 x 86 mm
Fan Size140mm
Fan BearingTwo Ball Bearing
Efficiency≥90% @ Typical Load
80 PLUS Rating80 PLUS Gold
ErP 2014 Lot 3Yes
Operating Temperature0-50°C
Power Good Signal100 - 150 ms
Hold Up Time≥16ms at 100% Load
MTBF>100,000 Hours
ProtectionsOVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection
RegulatoryTUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS
ATX 24 Pin Connectors1
EPS 4+4 Pin Connectors1
EPS 8 Pin Connector1
SATA Connectors12
Peripheral 4 Pin Connectors4
PCI-e 6+2 Pin Connectors3
12VHPWR Connector1
SeriesMWE Gold Series
CategoryAbove 750W
ModularFully Modular
80 Plus EfficiencyGold
Form FactorATX
Watts1250W
ATX VersionATX Rev. 3.0
PFCActive PFC
Input Voltage100-240V
Input Current15-7A
Input Frequency50-60Hz
Dimensions (L x W x H)180 x 150 x 86 mm
Fan Size140mm
Fan BearingTwo Ball Bearing
Efficiency≥90% @ Typical Load
80 PLUS Rating80 PLUS Gold
ErP 2014 Lot 3Yes
Operating Temperature0-50°C
Power Good Signal100 - 150 ms
Hold Up Time≥16ms at 100% Load
MTBF>100,000 Hours
ProtectionsOVP / OPP / SCP / OCP / UVP / OTP / Inrush Protection
RegulatoryTUV, cTUVus, CE, FCC, BSMI, CCC, EAC, RCM, UKCA, BIS
ATX 24 Pin Connectors1
EPS 4+4 Pin Connectors1
EPS 8 Pin Connector1
SATA Connectors12
Peripheral 4 Pin Connectors4
PCI-e 6+2 Pin Connectors3
12VHPWR Connector1
SeriesMWE Gold Series
CategoryAbove 750W
ModularFully Modular
80 Plus EfficiencyGold
Form FactorATX
Watts1250W
