Model Variants:
1TB, 2TB, 4TB
Controller:
PHISON E18
Flash Memory:
3D NAND
DRAM Cache:
1TB: 1GB DDR4
2TB & 4TB: 2GB DDR4
Form Factor:
M.2 2280
Interface:
PCIe Gen4 x4, NVMe 1.4
Backward compatible with PCIe Gen3, Gen2, and Gen1
Dimensions:
80mm (L) x 22mm (W) x 2.15mm (H)
Performance:
Sequential Read Speeds:
Up to 7400 MB/s
Sequential Write Speeds:
1TB: 6000 MB/s
2TB & 4TB: 7000 MB/s
Random Read Speeds (4KB):
1TB: 750,000 IOPS
2TB & 4TB: 1,000,000 IOPS
Random Write Speeds (4KB):
All capacities: 1,000,000 IOPS
Power Consumption:
Maximum Operating: 9.5W (1TB), 10.5W (2TB), 11.3W (4TB)
Idle Power: 40–50 mW
Low Power L1.2: 3 mW
Reliability:
Operating Temperatures:
0°C to 70°C
Storage Temperatures:
-40°C to 85°C
Durability:
1TB: 700 TBW
2TB: 1400 TBW
4TB: 3000 TBW
MTBF:
Up to 1,600,000 hours
Warranty:
5 years or until maximum TBW is reached
Advanced Features:
Performance Optimization:
TRIM support
Self-Monitoring:
SMART (Self-Monitoring, Analysis, and Reporting Technology)
Error Correction:
LDPC (Low Density Parity Check) ECC Algorithm
End-to-End Data Path Protection
Power Management:
APST (Autonomous Power State Transition)
Data Security:
AES256/Pyrite encryption
1TB, 2TB, 4TB
Controller:
PHISON E18
Flash Memory:
3D NAND
DRAM Cache:
1TB: 1GB DDR4
2TB & 4TB: 2GB DDR4
Form Factor:
M.2 2280
Interface:
PCIe Gen4 x4, NVMe 1.4
Backward compatible with PCIe Gen3, Gen2, and Gen1
Dimensions:
80mm (L) x 22mm (W) x 2.15mm (H)
Performance:
Sequential Read Speeds:
Up to 7400 MB/s
Sequential Write Speeds:
1TB: 6000 MB/s
2TB & 4TB: 7000 MB/s
Random Read Speeds (4KB):
1TB: 750,000 IOPS
2TB & 4TB: 1,000,000 IOPS
Random Write Speeds (4KB):
All capacities: 1,000,000 IOPS
Power Consumption:
Maximum Operating: 9.5W (1TB), 10.5W (2TB), 11.3W (4TB)
Idle Power: 40–50 mW
Low Power L1.2: 3 mW
Reliability:
Operating Temperatures:
0°C to 70°C
Storage Temperatures:
-40°C to 85°C
Durability:
1TB: 700 TBW
2TB: 1400 TBW
4TB: 3000 TBW
MTBF:
Up to 1,600,000 hours
Warranty:
5 years or until maximum TBW is reached
Advanced Features:
Performance Optimization:
TRIM support
Self-Monitoring:
SMART (Self-Monitoring, Analysis, and Reporting Technology)
Error Correction:
LDPC (Low Density Parity Check) ECC Algorithm
End-to-End Data Path Protection
Power Management:
APST (Autonomous Power State Transition)
Data Security:
AES256/Pyrite encryption
